Teacher Resource

Project

Fruit Fly Genetics Project

Molly Renner, Kathryn Orzech, and Lisa Schwartz

Learning Information

  • ToL Learner Level:
    • Intermediate
  • Target Grade/Age Level:
    • High School (Ages 15-18).
  • Learning Objective(s). Learners will:
    • Acquire knowledge about Drosophila melanogaster, specifically its classification, life cycle, and normal and mutant phenotypes.;
    • Design and conduct an experiment to cross wild type flies and mutant flies (either a white-eyed or a vestigial wing mutant) and make qualitative and quantitative observations about the parent, F1 and F2 generations of flies and phenotypes and presumed genotypes based on those phenotypes.;
    • Document the fruit fly experiments by creating ToL treehouse web pages.
  • Type of Activity
    • Classroom resource; Lab resource
  • Science Subject / Key Words
    • Genetics & Heredity;
    • Methods, Techniques, Apparatus
  • Additional Treehouse Type:
    • Investigation
  • Curricular Areas:
    • Language Arts;
    • Mathematics
  • Language:
    • English
  • Teaching and Learning Strategy:
    • Hands-on Learning;
    • Technology Integration/Computer Assisted Instruction
  • Grouping:
    • Small Group instruction

Introduction

This page describes our experience guiding groups of students through the dual process of conducting a basic genetics experiment with Drosophila melanogaster and documenting the project by creating Treehouse web pages. View a collection of the final products of this project in the Study of Fruit Fly Genetics at City High School Portfolio Treehouse.

Throughout the time students were conducting experiments with the flies, I (Molly Renner, biology teacher) interspersed lectures and homework related to genetics, DNA structure, etc.  Those sheets are not included in this page, as they focus on the genetics experiments conducted by students, and the process that they went through to complete the fly crosses and document their work on the Tree of Life.   Students were introduced to wild-type Drosophila (red eyes, normal wings) and also to two types of mutant flies (white-eyed and vestigial wings).  They chose a mutant and crossed that fly type with wild type flies to observe the results.  Most students chose to do reciprocal crosses, crossing wild males with (for example) vestigial females in Vial 1 and then wild females with vestigial males in Vial 2.  The Project section of this page describes our process for conducting and documenting these student experiments.

Preparation

Before beginning this activity, flies and supporting materials should be ordered from Carolina Biological Supply or another company that provides biological products for student use.

Physical Materials and Tools

  • Flies and supporting materials from Carolina Biological Supply or another company
  • Camera to capture images of flies and fly equipment
  • Blank paper to draw fly phenotypes, etc.
  • Computer (at least one per group) for construction of treehouse web pages

Prior Knowledge

Before or during the fruit-fly raising process, students should be familiarized with basic genetics vocabulary and practice making a 1-trait punnett square.

Project

Throughout this section, reference will be made to worksheets given to the students to guide them through the research process with their Drosophila melanogaster crosses.  These sheets may be accessed by clicking on the link provided here or by scrolling down to "Support Materials" below, where they are stored in the order that we used them.

Introducing Drosophila melanogaster

Several weeks prior to the start of the unit, I (Molly) ordered the flies (wild type, vestigial wing mutant, and white-eye mutant) and their supplies from Carolina Biological supply.  Shortly after they arrived,  I gave the students their first introduction to the flies and asked them to make expansion vials so that we could increase the number of flies as instructed by the Carolina Drosophila manual.

document iconView InstructionsforDrosophilaMedium022706.doc

In addition to having students research basic information such as classification and life cycle from their textbook and the Drosophila manual, I also asked them to perform an initial assessment of their groups' strengths and weaknesses as well as their availability to come in before or after school to count flies when needed.

document iconView IntrotoDrosophiliamelanogaster022706.doc

document iconView DrosophilaGroupStrengthsWeaknesses022706.doc

The final piece of introduction to Drosophila was a worksheet the students completed on fly phenotypes that familiarized them with genetic notation as well as the appearance of the wild-type and mutant flies.

document iconView Phenotypes030206.doc

Students were also asked to draw the various fly phenotypes.



Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Vestigial wing vs. Wild Type © 2006 fivenavy1





Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Red-Eyed (Wild Type) vs. White-Eyed © 2006 threeyellow3



Male or Female Flies?

In order to make sure students understood the genetic basis of sex as related to sex chromosomes, I asked them to answer some questions based on reading from their biology textbook as well as to take lecture notes as I spoke briefly about this topic.

document iconView SexChromosomes030306.doc

I also wanted to make sure they had the more practical skill of telling male and female fruit flies apart, as this is critical for crossing the flies successfully. Students completed the worksheet below and also did a "practice run" for fly sexing, learning how to use the Fly Nap and then sorting the sleeping flies into male and female piles.

document iconView MaleandFemaleFruitFlies030606.doc

Students were also asked to draw the difference between male and female flies. This was usually a drawing of fly abdomens copied from the Carolina Drosophila manual, but sometimes students got more creative.



Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

© 2006 fruitflygreen4



Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Female fly on the left, Male on the right © 2006 twored3



Introducing the Tree of Life

After students had been exposed to basic information about the flies, I, with Kathryn's help, introduced the Tree of Life website to students.  Kathryn did a short presentation on the site and provided students with a paper to keep track of their username and password when they logged into the site.  I had made colored folders for the students in each group to help them keep their fly materials together, so we used their class period and folder color to assign usernames in the ToL (for example, the 2nd period "Red" group would be twored and its members would be twored1, twored2, twored3, and twored4).

document iconView IntroductiontotheTreeofLifeNotesandInstruct031006.doc

Making the Crosses - Parent and F1 Generations

After an appropriate number of wild type, vestigial and white-eyed flies had grown to maturity, students performed their parent crosses.

 Wild Type Flies
Vestigial Wing Flies
White-Eyed Flies

Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

© 2006




Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

© 2006




Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

© 2006







Before actually putting flies in vials, they completed this sheet so they would have a record of what they did.

document iconView ParentCross031306.doc

Also in this time frame, I asked students to complete an initial self-check of their group folders to make sure each person had the appropriate worksheets completed.

document iconView FlyFolderIndividualWorkGradingCheck1.doc

Approximately a week later, after the parent generation flies had grown to maturity, students made their F1 predictions (drawing punnett squares to illustrate their predictions if the trait of interest to them (vestigial wings or white eyes) was autosomal or sex-linked.

document iconView F1Predictions032106.doc

Providing More Guidance for Website Content

Kathryn developed a checklist for items to include in the Treehouse website.  We ended up not using a few of the items (for example, an audio recording), adding a few things (the F1 Outcomes and Eulogies the students wrote for their flies)  and changing others (a chi-square analysis became a percent-error calculation) but the checklist helped students stay on task when they were making their websites.

document iconView ChecklistContentforEachGroupsWebpage032006.doc

 Kathryn also conducted a short lesson with students, asking them to think about what makes a good website and giving them some instruction on how to format their sites.

document iconView WEBSITEDESIGN032706.doc

Midpoint Group Reflection

Around this time, I also asked the student groups to assess themselves on how they were doing as a group.  Students completed a 2-page assessment that asked them what was working in their groups, what was not working, and how they thought they could improve.

document iconView MidpointGroupReflection032006.doc

Outcomes from the F1 Generation and Predicting F2

Students had spent a few days setting up their websites, but without the rest of the experiment, they wouldn't say much.  Approximately one month after we started the fly experiments, students napped their F1 generation and observed their phenotypes.



Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Flies in a Nap vial © 2006

movie iconView Flies Ready to Be Napped

 (NOTE: This is a 13-second clip that takes about 2 mins to download on DSL)



Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Sorting flies by sex and observing phenotypes© 2006

Students used this sheet as they made their observations to  note the phenotypes and probably genotypes of their flies before  crossing F1 males and females in two new vials to create the F2 generation.

document iconView F1Outcomes033106.doc

A few days later, students made predictions about their F2 outcomes.

document iconView F2Predictions040306.doc

Self Checking Fly Folder Work

Several days after students made their F2 predictions, I asked them to go through their group folders and make sure each student had the proper worksheets completed.

document iconView FlyFolderIndividualWorkGradingCheck2.doc

F2 Outcomes and Percent Error Calculations

Close to two months after starting the fly genetics unit, students had almost completed their experiments. Students napped and counted their F2 generation flies every other day for approximately 1.5 weeks (generally 3 to 4 distinct counting occasions).  They kept track of how many flies of each phenotype they counted using this form.

document iconView F2Outcomes041706.doc

Once they completed their counting, students used this form to calculate their percent error for each of their two vials and assess whether their initial hypothesis about their mutation (it was autosomal, it was sex-linked) was correct.  They also completed several questions that led directly into the conclusions they drew on their group webpages.

document iconView ComparisonsPercentError042506.doc

Completing the Tree of Life Website

Students spent 3 to 4 (50-minute) class periods finishing their websites.  I helped them with ideas for what to include in the introduction and conclusion by providing them with these instructions:

document iconView SuggestionsforWebsiteIntroandConclusion042706.doc

Final Notes

As some of my students were completing my biology course for Honors credit, I set up a set up a series of questions that students answered about the "Honors Fly Crosses" where flies with multiple mutations were crossed (for example, vestigial wing, white-eyed) and students had to make more complex predictions and do more fine-grained sorting of phenotypes.

document iconView HonorsFruitFlyQuestions.doc

Near the end of the project, Kathryn set up a PowerPoint presentation to show parents and community members what students had been doing as part of the fruit fly genetics unit.

document iconView FruitFlyGeneticsPictures.ppt



Evaluation

I created a rubric that took into account whether students included all required sections in their page and paid particular attention to their introduction and conclusion to demonstrate their understanding of the project and what they had learned by the end of the experiment. I also awarded points to students who took time to format their web submission in a professional way. Please see the rubric under "Support Materials" below.

Portfolio Pages

Fruit Fly Genetics at City High School
© 2006 fruitflyyellow2
View the outcome of students' projects in their treehouse webpages! This portfolio treehouse contains links to students' investigations.
